Supply of TPPI 1000/10/0.4 for Solar Power Plant 1 MW
EDS-POWER has produced an inverter complete transformer substation with an open area for placing inverters (TPPI) at 10/0.4 kV to receive electricity from solar panels, convert it with inverters, and transmit it to the grid for the Customer.
The TPPI will serve an industrial solar power plant with a capacity of 1 MW in the Kyiv region.
TPPI Housing - block housing manufactured by our company.
High Voltage:
- PAC - Prefabricated chamber of unilateral service 10 kV - 1 unit;
- PAC - Prefabricated chamber TN 10 kV - 1 unit.
LVSW:
- LVCS - Low-voltage Complete Switchgear;
- CS - Cabinet of own needs.
Transformer compartment:
- Power transformer TOS-1000 kVA 10/0.4 kV-U1.
Inverter compartment, open area:
- Grid inverter HUAWEI SUN2000-100KTL - 8 units;
- Huawei Smart Logger 3000A no PLC.
video of the TPPI assembly process before shipment here
manufactured by EDS-POWER.
